+Features
✧ With medical grade oxygen concentration above 93%, better treatment effect for patients with pulmonary fibrosis;
✧ Innovative cooling technology to ensure 24/7/365 operation;
✧ Humidifier bottle with a pressure relief value of 6PSI, safer and more comfortable;
✧ Four flexible castors with two brakes, easy to move or situate in any direction, safer and more convenient;
✧ Simple operation functions and easy-to-read LCD Display;
✧ Connected to HFNC, provide oxygen with stable high concentration, more comfortable;
✧ Connected to HBOC, rapidly and effectively increase the patient's SPO2.
Specification
| JAY-3AW ; JAY-5AW | |||
| Flow Rate |
3L/min for JAY-3AW 5L/min for JAY-5AW |
Net weight | 16Kgs |
| Oxygen Concentration | 93% (±3%) | Power Consumption | ≤ 280W/≤ 300W |
| Outlet Pressure |
6-10PSI(0.04-0.07mpa); |
Input Frequency | 50Hz ; 60 Hz |
| Input Voltage | AC230V ± 10% ；AC110V ±10% | ||
| Alarm |
1. Power failure alarm; 2. High and low pressure alarm; 3. Low oxygen concentration alarm: When oxygen purity is >82%, blue light illuminate; When oxygen purity is <82%, red light illuminate , indicating low purity ; |
||
Applications
✧ Oxygen therapy according to the doctor's prescription;
✧ Oxygen inhalation is vital to patients with breathing-related disorders like pulmonary disease, ARDS, pneumonia, lung injuries, bronchitis, asthma,
etc;
✧ It can be used in conjunction with HFNC, HBOC or BIPAP.
If connected to HFNC, it provides oxygen with a stable high concentration, making it more comfortable;
If connected to HBOC, it rapidly and effectively increases the patient's SPO2;
If connected to BIPAP, this makes it convenient for COPD patients to have oxygen therapy at home.
