+Features
✧ Hypoxic purity 9%-20.9% to simulate different altitudes;
✧ With both hypoxic outlet and oxygen outlet for different demands;
✧ Countinuous operation 24/7;
Specification
| Model | JAY-10H | JAY-20H | JAY-40H | JAY-60H |
| Hypoxic Flow | 100LPM | 200LPM | 400LPM | 600LPM |
| Hypoxic Concentration | 9%-20.9% | |||
| Outlet Pressure | 6-10Psi | |||
| Oxygen Concentration | 93%(±3%) | |||
| Simulated Altitude | 0-6500m(0-21330ft) | |||
| Sound Level | ≤50dB | ≤55dB | ≤58dB | ≤60dB |
| Power Consumption | ≤550W | ≤1100W | ≤2200W | ≤3300W |
| Alarms | Power failure alarm,high / low pressure alarm | |||
| Net Weight | 27kgs | 95kgs | 160kgs | 245kgs |
| Dimension | 365*375*600mm | 600*400*1380mm | 760*540*1380mm | 760*540*1960mm |
| Optional | 1. Pulse oximeter; 2.Monitor system | |||
Applications
✧ The hypoxic training system consists of hypoxic generator, oxygen controller and LCD monitor, which is widely used in sports centers, national sports bureaus and gyms to improve athletes'physical performance;
✧ It can simulate different altitudes from 0-5000 meters, achieve hypoxic purity from 9% to 20%;
✧ Each room is also equipped with LCD monitor to show the hypoxic purity, temperature, humidity, altitude and CO2 content;
✧ The central monitor can collect all datas from individual LCD monitor in each room, thereby monitoring the changes in SpO2, blood pressure and pulse of each athlete during simulated altitude training
✧ Equipped with wrist or finger-clip oximeter to monitor athletes Spo2 & pulse at any time and upload the datas to the central monitor
