Features
✧ Easy to install and can be installed indoors, which can quickly increase the user's SpO2;
✧ Low noise design with 4-cylinder compressor helps improve sleep quality and can be used indoors;
✧ Intelligent terminal & large screen display can monitor temperature,humidity and sea level;
✧ Low power consumption and energy saving.
Specification
Model | JAY-10M | JAY-20M | JAY-40M | JAY-60M |
Flow Rate | 0-10L | 0-20L | 0-40L | 0-60L |
Outlet Pressure |
6-10Psi/20Psi |
6-10Psi/20Psi (0.04-0.07Mpa/0.14Mpa) |
6-10Psi/20Psi (0.04-0.07Mpa/0.14Mpa) |
6-10Psi/20Psi (0.04-0.07Mpa/0.14Mpa) |
Oxygen Concentration | 93%(±3%) | 93%(±3%) | 93%(±3%) | 93%(±3%) |
Sound Level | ≤43dB | ≤48dB | ≤58dB | ≤60dB |
Power Consumption | ≤600W | ≤1200W | ≤2200W | ≤3300W |
Alarms | Power failure alarm, High/low pressure alarm |
Power failure alarm, High/low pressure alarm |
Power failure alarm, High/low pressure alarm |
Power failure alarm, High/low pressure alarm |
Weight | 160Kgs | 245Kgs | ||
Dimension | 530*440*780mm | 530*440*1380mm | 760*540*1380mm | 760*540*1960mm |
Home oxygenation system is an oxygen control equipment to simulate sea-level. By adding higher oxygen concentration of oxygen into the tent or the room, we can bring any high altitude space back down to sea-level. This system can convert literally any size space to a high oxygen, seal-level environment. We can provide mutiplle control panels so that each room can be independently controlled.
Applications
✧ WHO CAN BENEFIT: This system is ideal for residents who live in plateau area or those with high altitude country homes or for hotels and resorts that cater to sea-level residents coming to high altitudes for skiing and other adventures;
✧ WHAT SPACES: For bedrooms, offices at hotels, resorts, military camp, government, schools in plateau area and some refined spaces such as sauna rooms in plain area;
✧ COUNTRIES AND REGIONS: Peru, Chile, Bolivia, Venezuela, Colombia, Ecuador, Mexico, Argentina, Ethiopia, Armenia and various border zones in highland areas such as the Sino-India border plateau.
