+Features
✧ Convenient to be installed anywhere；
✧ Availble to connect oxygen tank, and optional function with auto-on (1 bar pressure) & auto-off (1.4 bar pressure), ensure the system longer lifespan；
Specifications
| JAY-15 ; JAY-20 ; JAY-30 ; JAY-40 ; JAY-60 | |||
| Flow Rate | 0.9m³/h ; 1.2m³/h ; 1.8m³/h ; 2.4m³/h ; 3.6m³/h | Net Weight | 90Kgs ;95Kgs ; 140Kgs ;160Kgs ; 245Kgs |
| Oxygen Concentration | 93% (±3%) | Power Consumption | ≤600W ; ≤1200W ; ≤1650W ; ≤2200W ; ≤3300W |
| Outlet Pressure | 6-10PSI / 20PSI / 60PSI | Input Frequency | 50Hz ; 60 Hz |
| Sound Level | 43dB / 48dB / 58dB / 58dB / 60dB | Input Voltage | AC 230V± 10% ; AC110V ± 10% |
| Alarm |
1. Power failure alarm; 2. High and low pressure alarm; 3. Low oxygen purity alarm: |
||
Applications
✧ For high pressure cylinder filling plant.
